Battery Data
Cell Material
LFP
Cycle Life
>6000 cycles (25℃, DOD 90%, 0,5C/0,5C, SOH 70%)
Capacity
896Wh
Battery Level Display
4-segment LED
(green LED display battery level and red LED displays alarm prompt)
Shipping SOC
50%~60%
Input Data
AC Input Power
250W Max
AC Input Voltage
150~264V, 50/60Hz
PV Input
12~36V/10,5A Max/200W Max
Output Data
Total AC Output Power
300W Max
AC Output Voltage
210~230V 50/60Hz
UPS Function
20ms
DC Output
TYPE-C 5V/9V/12V, 4A Max 20W
USB-A 5V/9V/12V, 4A Max 20W × 2
Environmental and Mechanical
Nominal Dimensions (W × H × D)
290mm × 248mm × 168mm
Nominal Weight
≤9kg
Cooling
Air cooling
Charging Temperature
0℃~45℃
Discharging Temperature
-10℃~45℃
Optimum Charging And Discharging Temperature
20℃~30℃
Storage Temperature
-20℃~45℃
Sleep Current
Less than 1mA (ARM sleep, DSP power down)
Certification
Cell Material
EC/EN62109, IEC/EN62619, VDE-AR-N 4105-2018
IEC/EN 61000-3-2/-3 EN300328, UN 38.3
